Stella™ LR
Overview
The redesigned LR copper/brass up light continues its legacy as a beautiful, robust addition to lighting projects in coastal environments.
- Copper/brass construction
- Accepts MR-16 lamps
- Phase and PWM dimmable
- Premium copper or brass finishes
- ProAim™ adjustability
- Input voltage: 10-15V
Configure Product
Select from the options below to configure this product, then add it to your My List.
Lamp
E6
6.0 VA MR-16 Lamp (Eco Lamp Series)
LED20
4.3 VALED MR-16 Lamp (PRO Lamp Series)
LED35
5.4 VA LED MR-16 Lamp (PRO Lamp series)
LED50
6.5 VA LED MR-16 Lamp (LED Lamp series)
NL
Lamp Not Included
E9
9.0 VA MR-16 Lamp (Eco Lamp Series)
LED Color
[Default]
No Lamp
W
Warm (2700K)
Optic
[Default]
NL Lamp
FL
Flood (35°)
WF
Wide Flood (60°)
Glare Control
[Default]
Flat Shroud
LS
45º Angled Long Shroud
Finish
Natural Copper (CU)
Accessories
Select Type
- All Accessories
- Recommended
- Power
- Mounting
- Filters
- Splicing
- Glare
- Lenses
- Replacement Lamps
PM-XX*
Post Mount
GM-XX*
Ground Mount with ½" Thread
VB-050-XX*
VersaBox® Mount with ½" Thread
250015840000
Long Slot Spike
250020020000
Three-Prong Spike
SJ-XX*
Super J-Box Spike
YY*-R-GT-XX*
1.0" (25 mm) Copper Riser for GT Path Light
PARS
ProAim® Ratcheting Spike
250030410000SP
Lock Ring
250015260000
Hex Baffle for MR-16 LED Lamps
250015170000
Frosted Lens for MR-16 LED Lamps
250015240000
Solite Spread Lens for MR-16 LED Lamps
250013550000
Linear Spread Lens for MR-16 LED Lamps
250015180000
Dichroic Lens for MR-16 LED Lamps, Light Green
250015200000
Dichroic Lens for MR-16 LED Lamps, Light Blue
250015230000
Dichroic Lens for MR-16 LED Lamps, Peach
250015190000
Dichroic Lens for MR-16 LED Lamps, Blue
250015210000
Dichroic Lens for MR-16 LED Lamps, Green
250015220000
Dichroic Lens for MR-16 LED Lamps, Red
MR16-ZD-XX-Y-ZZ
ZD MR-16 LED Lamp
Specifications
| Output | LED20W | LED35W |
|---|---|---|
| Total Lumens (lm) | 240 | 335 |
| Input Voltage | 10 to 15V | 10 to 15V |
| Input Power (W) | 4.0W | 5.0W |
| Power Consumption (VA) | 4.3W | 5.4W |
| Efficacy (Lumens/Watt) | 60 | 67 |
| Color Rendering Index (CRI) | 81 | 81 |
| Luxor Compatibility | ||
|
ZD Option |
Use ZD MR-16 Lamp | Use ZD MR-16 Lamp |
| Minimum Rated Life (L70) | 40,000 Hrs | 40,000 Hrs |
**For optimal performance, use a trailing edge phaser cut dimmer.
CB Scheme, CE, RoHS, RCM, NOM UL 1838
The Luxor Controller utilizes Luxor Technology to zone luminaires in up to 250 groups, dim each group in 1% increments between 0% and 100%, or change to one of 30,000+ colors with RGBW LEDs. Select the ZD option for zoning/dimming.
Made In Mexico
CSA C22.2 NO. 250.7
EN 55015,EN 61000-3-2,EN 61000-3-3,EN 61547
Outdoor
FCC CFR Part 15 Subpart B
Natural metal finish.
Brass and/or stainless steel hardware
Standard MR-16 lamp
10 to 15 VAC/VDC, 50/60 Hz. Remote transformer required (specify separately)
UL 1838. Compliant per IEC 60598-1 and IEC 60598-2-4 when used with the Ground Mount (“GM-XX”) or alternate mount greater than or equal to IP65.
IP65
ICES-005
Cree®
L70 rating conforms to IES LM-80/TM-21 standards, projecting lumen maintenance to 70% of initial output.
EN 60598-1,EN 60598-2-4
Die-cast C360 brass knuckle/bass assembly with brass hardware and machined angled glass support. C110 extruded copper shroud.
Beam angles dependent upon selected lamp.
Specified power consumption indicates the full apparent power.
Innovation meets conservation in the design and manufacturing of our products. Where we can, we use recycled materials while maintaining superior functionality. Our LED products provide high-quality light at optimal energy efficiency, lifespan, and durability.
2.6
MR-16 GU5.3 socket with retaining clips. Ceramic socket base with heat-resistant contact pad. Stainless steel retaining clips ensure high spring force retention.
