MR-16 Eco

Overview

The MR-16 Eco LED lamp family provides a high-quality, economical choice for lighting professionals. The lamps are available in two intensities, two beam angles, and two color temperature options.

Quick Facts

Lightweight aluminum housing
Beam angle options: 30° (Flood) and 60° (Wide Flood)
Two intensities: 6 VA and 9 VA
Warm color temperature: 2,700K
Compatible with the Luxor® Low-Voltage Cube (LCM-LV)

Lighting Engine

MR-16

Power

6

6 VA

9

9 VA

LED Color

W

Warm (2700K)

S

Soft (3000K)

Optic

FL

Flood (30°)

WF

Wide Flood (60°)

Product Configuration

Clear Selection

Quantity

–

+

Notes

Accessories

Select Type

All Accessories
Recommended
Power
Mounting
Filters
Splicing
Glare
Lenses
Replacement Lamps

Power

Luxor Cube - Low-Voltage

LCM-LV

Adds zoning and dimming capabilities to other brands lighting fixtures and outdoor elements

Learn more

Low-Voltage Dimmer

DIM-LV

The Low-Voltage Dimmer provides in-line dimming control for any low-voltage fixture. It’s the ideal

Learn more

Glare

Hex Baffle for MR-16 LED Lamps

250015260000

Shield used to increase glare control with up or down lights. Ideal for fixtures installed near

Learn more

RecessorRing® Spacer for MR-16 LED Lamps

RR-MR16

Spacer pushes the lamp farther into the fixture body to prevent glare and change the look of the

Learn more

Lenses

Frosted Lens for MR-16 LED Lamps

250015170000

A 2.0" (50 mm) frosted lens that diffuses the light to produce a soft wash look or maximize blending

Learn more

Solite Spread Lens for MR-16 LED Lamps

250015240000

A 2.0" (50 mm) pebbled lens that slightly minimizes the light’s intensity while softening the edges

Learn more

Linear Spread Lens for MR-16 LED Lamps

250013550000

A 2.0" (50 mm) lens featuring ridges that spread the light in a linear direction. The result is a

Learn more

Dichroic Lens for MR-16 LED Lamps, Light Green

250015180000

A 2.0" (50 mm) glass lens that creates a soft green light output. Includes UV protection to prevent

Learn more

Dichroic Lens for MR-16 LED Lamps, Light Blue

250015200000

A 2.0" (50 mm) glass lens that creates a 4,000K light blue output. Includes UV protection to prevent

Learn more

Dichroic Lens for MR-16 LED Lamps, Peach

250015230000

A 2.0" (50 mm) glass lens that creates a soft white light output. Includes UV protection to prevent

Learn more

Dichroic Lens for MR-16 LED Lamps, Blue

250015190000

A 2.0" (50 mm) glass lens that creates a 5,200K cool blue light output. Includes UV protection to

Learn more

Dichroic Lens for MR-16 LED Lamps, Green

250015210000

A 2.0" (50 mm) glass lens that creates a saturated green light output. Includes UV protection to

Learn more

Dichroic Lens for MR-16 LED Lamps, Red

250015220000

A 2.0" (50 mm) glass lens that creates a saturated red light output. Includes UV protection to

Learn more

Specifications

Download Spec Sheet

	E-6-FL	E-6-WF	E-9-FL	E-9-WF
Total Lumens (lm)	490	440	635	565
Power Consumption (VA)	6.0	6.0	8.5	8.5
Efficacy (Lumens per Watt)	130	115	110	100
Correlated Color Temperature (CCT)	2700K	2700K	2700K	2700K
Halogen Equivalent (W)	35	35	50	50
Beam Angle	30°	60°	30°	60°
Maximum Candela (cd)	1,075	310	1,505	410
Color Rendering Index (CRI)	83	83	83	83
Input Voltage (V)	10-15	10-15	10-15	10-15
Dimming	Phase	Phase	Phase	Phase
Minimum Rated Life (L70)	30,000 Hrs	30,000 Hrs	30,000 Hrs	30,000 Hrs

Additional Certifications

RoHS

Ambient Operating Temperature

0°F to 140°F (-18°C to 60°C)

Country of Origin

Made In China

Description

MR-16 Lamp, Eco Series

Environment

Outdoor

FCC

FCC CFR Part 15 Subpart B

HTS Code

Input Voltage Specification

10 to 15 VAC/VDC, 50/60 Hz. Remote transformer required (specify separately)

ISED

ICES-005

Lifetime Specification

L70 rating conforms to IES LM-80/TM-21 standards, projecting lumen maintenance to 70% of initial output.

Power Consumption Specification

Specified power consumption indicates the full apparent power.

Sustainability

Innovation meets conservation in the design and manufacturing of our products. Where we can, we use recycled materials while maintaining superior functionality. Our LED products provide high-quality light at optimal energy efficiency, lifespan, and durability.
